NX-6510S-20X4S2Q -2.56T/23.04T Switching Capacity - Multicasting - High Speed - 4MB Port Buffer - Metal Hardware - Stackable

Nodexon’s Core Aggregation Switch series presents NX-6510S-20X4S2Q as a highly modified 10G Ethernet switch. They are capable of powerful performance and high security for systems. It also provides faster hardware processing performance and a convenient operating experience. NX-6510S-20X4S2Q provides maximum 32 10G fiber access and supports high-performance 10/25/40G port uplink, Making sure we fully meet the user's expectation of high-density access and high aggregation performance.

Aggregation Switches

Key Features

  • Arrow 32 x 10G Base-X Access Ports.
  • Arrow Built-in Layer 3 Advanced Routing Support.
  • Arrow Hot Swappable Power & Fan Redundancy.
  • Arrow 4 25G & 2 40G uplink.
  • Arrow Robust High Reliability Hardware Design.

Similar Models

NX-3875-28S4X<

NX-3875-28S4X

28-Port SFP L3 Managed Switch with SFP+
NX-3875-48G4XH

NX-3875-48G4XH

48-Port Gigabit L3 Managed POE+ Switch with SFP+

NX-3875-28G4X

NX-3875-28G4X

28-Port Gigabit L3 Managed Switch with SFP+
NX-3875-48G4X

NX-3875-48G4X

48-Port Gigabit L3 Managed Switch with SFP+
Performance

Performance

  • Arrow Support the IPv4 and IPv6 multicast functions.
  • Arrow Support IGMP snooping, IGMP, MLD, PIM, MSDP.
  • Arrow Compatible with standard protocols.
Network Management

Network Management

  • Arrow SNMP, RMON, Syslog, Logs And Configuration Backup.
  • Arrow Command Line Interface (CLI).
  • Arrow Web Management, Telnet, FTP/TFTP v6, DNS v6, NTP for v6, Traceroute v6.
  • Arrow Support sFlow.
Layer Switching

Layer Switching

  • Arrow Ipv4/Ipv6 Dual-Stack Multilayer Switching At Line Rates.
  • Arrow Distinction And Processing Of Ipv4 And Ipv6 Packets By Hardware Supported.
  • Arrow Ipv4 Router Protocol including Static Routing, RIP, Ospfv2, IS-Isv4, BGP4.
Data Center Virtualization

Data Center Virtualization

  • Arrow Enables interconnection via link aggregation..
  • Arrow Uses one single IP address, Telnet process, command-line interface (CLI).
  • Arrow Enables auto version inspection and configuration .
Energy Flow

Energy Flow

  • Arrow Open Flow.
  • Arrow 1 + 1 Hot Swappable Power Supplies.
  • Arrow Left-to-Right Airflow.
VLAN
4K 802.1Q VLAN, Port-based VLAN, Private VLAN, GVRP Super VLAN
QinQ
Basic QinQ
Link aggregation
LACP (802.3ad)
MST Instances
64
Spanning tree protocols
STP, RSTP, MSTP
Maximum Aggregation Port (AP)
128
IPv6 protocols
IPv6 addressing, ICMPv6, Path MTU Discovery
IP routing
Static routing, RIP, RIPng OSPFv2, OSPFv3, IS-ISv4, IS-ISv6, BGP4, BGP4+, ECMP
VSU (Virtual Switch Unit)
Up to 2 stack members
Supported power module
RG-PA150I-F
Fixed ports
20 1G/10GBASE-X SFP+ ports,
4 10G/25GBASE-X SFP28 ports,
2 40GBASE-X QSFP+ ports,
Support up to 32 10G ports,
2 modular power slots,
2 modular fan slots.
Management ports
1 MGMT port
1 console port
1 USB port
Switching capacity
2.56T/23.04T
Packet forwarding rate
570Mpps/1260Mpps
Port Buffer
4MB
ARP Table
Up to 16K
MAC Address
Up to 32K
Routing Table Size (IPv4/IPv6)
4K/4K
ACL Entries
Up to 2500
